MSI MEG Z690 GODLIKE

Overview:

The MSI MEG Z690 GODLIKE is an ultra-premium flagship motherboard built for enthusiasts, overclockers, and professional creators using Intel’s 12th and 13th Gen Core processors. With its E-ATX form factor, extreme VRM architecture, advanced thermal design, and a feature set unmatched by most consumer motherboards, the Z690 GODLIKE delivers maximum stability and performance.
Featuring DDR5 support, PCIe 5.0 expansion, next-generation networking, Thunderbolt 4, and MSI’s exclusive M-VISION dashboard, this motherboard sets the standard for luxury, innovation, and extreme computing capability.

Full Specifications:

• Chipset: Intel Z690

• CPU Support:

  • Intel 12th & 13th Gen Core processors

  • Socket LGA 1700

• Form Factor: E-ATX

• Memory Support:

  • DDR5

  • Up to 128GB (4 DIMMs)

  • Extreme overclocking support (6666MHz+ depending on CPU)

• VRM Design:

  • 20+2+1 phase power delivery

  • 105A Smart Power Stages

  • Premium heatsinks with fin array & heatpipe cooling

• Expansion Slots:

  • PCIe 5.0 x16 slots (Steel Armor)

  • Additional PCIe 4.0 slots

• Storage:

  • 6 × onboard M.2 slots (PCIe 4.0)

  • 2 × PCIe 5.0 M.2 slots via M.2 XPANDER-Z GEN5 Dual card

  • 6 × SATA III ports

• Networking:

  • 10G LAN

  • 2.5G LAN

  • Wi-Fi 6E

  • Bluetooth 5.x

• Rear I/O:

  • Thunderbolt 4 / USB4 Type-C

  • USB 3.2 Gen 2x2 Type-C

  • Multiple USB 3.2 high-speed ports

• Audio:

  • Realtek ALC4082

  • ESS SABRE Hi-Fi DAC

  • Isolated high-fidelity audio circuitry

• Special Features:

  • M-VISION 4.5" touch dashboard

  • Dynamic OLED panel for monitoring & control

  • Dual BIOS

  • Debug LEDs, OC buttons, Clear CMOS, BIOS Flashback

  • Reinforced PCIe & DIMM slots

  • Mystic Light RGB headers

• Cooling Support:

  • Multiple PWM fan headers

  • Dedicated pump headers

  • Full M.2 Shield Frozr coverage

• Ideal For:

  • Enthusiast overclocking

  • Extreme gaming PCs

  • High-end content creation & workstations

  • Luxury showcase builds
