MSI MEG Z690 ACE

Overview:

The MSI MEG Z690 ACE is a premium high-end motherboard built for enthusiasts and professionals using Intel 12th and 13th Gen Core processors. Featuring a powerful VRM design, advanced DDR5 support, PCIe 5.0 capability, and high-speed connectivity, the Z690 ACE delivers outstanding performance for gaming, overclocking, and workstation workloads.
With its elegant black-and-gold aesthetic, extensive M.2 storage options, Thunderbolt 4 integration, and cutting-edge networking, the MEG Z690 ACE is designed for builders who want top-tier reliability and premium features without stepping into full GODLIKE territory.

Full Specifications:

• Chipset: Intel Z690

• CPU Support:

  • Intel 12th & 13th Gen Core processors

  • Socket LGA 1700

• Form Factor: E-ATX

• Memory Support:

  • DDR5

  • Up to 128GB (4 DIMMs)

  • High-frequency OC support (up to 6600MHz+ depending on CPU)

• VRM Design:

  • 19+1+2 phase power delivery

  • 105A Smart Power Stages

  • Premium heatsinks with heatpipe system

• Expansion Slots:

  • 2 × PCIe 5.0 x16 (Steel Armor)

  • 1 × PCIe 4.0 slot

• Storage:

  • 5 × M.2 slots (PCIe 4.0)

  • 6 × SATA III ports

• Networking:

  • Dual LAN: 2.5G + 10G

  • Wi-Fi 6E

  • Bluetooth 5.x

• Rear I/O Ports:

  • Thunderbolt 4 / USB4 Type-C

  • USB 3.2 Gen 2x2 Type-C

  • Multiple USB 3.2 Gen 2 & Gen 1 ports

• Audio:

  • Realtek ALC4082 audio processor

  • ESS SABRE Hi-Fi DAC

  • Isolated audio circuitry with premium capacitors

• Internal Features:

  • Debug LEDs

  • BIOS Flashback + Clear CMOS

  • Reinforced slots

  • Mystic Light RGB headers

  • High-quality VRM cooling and M.2 Shield Frozr

• Cooling Support:

  • Multiple PWM fan headers

  • Pump and AIO headers

  • Extended heatsink design

• Ideal For:

  • High-end gaming

  • Overclocking

  • Content creation & productivity

  • Premium enthusiast builds
